RATED OUTPUT

650W

RATED WIND SPEED  m/s / mph

10.5 / 24

PEAK OUTPUT

750W

CUT IN  m/s / mph

2.7 / 6

YAW SYSTEM

Passive by tail Vane

YAW / Tower Cable

N x 360° Freedom

GENERATOR

PM 3 phase alternator(variable speed )

Insulation Class & Efficiency

Class “H”, > 87%

Stator Skew

1 slot pitch

Max stator Core Temperature

180° C

POLES

10

RPM- 50hz/60hz

600 / 720

Over speed limit RPM / Hz

840/70

Monthly KWH 10mph  / 4.5 m/s PLF %

72 kWh (18%)

Monthly KWH 12mph  / 5.4 m/s PLF (%)

161 kWh (25%)

ROTOR DIAMETER

2.2m / 7.2 ft

NUMBER OF BLADES

3

BLADE MATERIAL & Cp

Carbon Fiber composite, ~ 0.37

SWEPT AREA

3.7 /43 Sq.m / sq.feet

Minimum Tip clearance cm / in

20 / 8

Tip Speed Ratio ( TSR )

8.5

LATERAL THRUST ( MAX )

1260 nts

GOVERNOR / over speed limit

Uptilt tilt

GOVERN SPEED

27mph

GOV. SHUT-DOWN  / OPTIONAL STOP

Electro- dynamic Switch

UNIT WEIGHT (tower top )

23 kg to 39 Kg.

TOWER Top Pipe / Yaw adaptor

P 2.5” Shd, 40

VOLTAGE options

12 to 48  / 60 - 140 LV    /    HV

ELECTRONIC CONTROLLER

Incl. but separate

WARRANTY

2 yrs.

OPERATING LIFE

20 yrs.

SURVIVAL WIND

55 m/s

SUGGESTED.  ROUTINE MAINTENANCE

Annual inspection
